Xcel-Arc Viper MIG165 Synergic MIG/MMA/TIG

$877.00 incl. GST

$762.61 excl. GST

Our Part #: WE20172 ~ Supplier Part #: XA-MIG165V-K

Our Part # WE20172 ~ Supplier Part #: 0

Description

The VIPER™ 165 is the ultimate multi-process welder for the DIY enthusiast. MIG, TIG or STICK, the VIPER™ does it all, and it’s ready to go anywhere you have a standard 10-amp outlet. Get repairs done and see your projects come together in record time with the ability to change modes with the flick of a switch.

The VIPER™ 165 is the perfect solution for those looking for insane performance without needing to blow your budget on multiple welders.

SYNERGIC PROGRAMS
TAKE THE GUESSWORK OUT OF SETUP

GEARED WIRE DRIVE
FOR SMOOTHER WIRE FEEDING.

GAS & GASLESS MIG
EASILY RUN MILD STEEL & FLUX-CORED MIG WIRE.

10 AMP PLUG
Plug in and play. A 10 AMP power plug can be used on any domestic outlet. It’s perfect for the DIY home handyman or the professional welder looking for a machine that can be used almost anywhere.

MULTI-PROCESS WELDING
This three in one machine, lets you perform MIG, TIG and STICK welding all on one machine. There is also support for both gas shielded MIG and gasless MIG wire. There is no need to swap between machines, saving you time and setup.

Features

PRIMARY INPUT VOLTAGE
230V Single Phase
SUPPLY PLUG
10 AMP
RATED INPUT POWER (kVA)
5.9
Ieff (A)
9.8
PROTECTION CLASS
IP21S
INSULATION CLASS
H
POWER FACTOR
0.72
DINSE CONNECTOR
35/50
STANDARD
AS/NZ60974-1
SUITABLE MATERIAL
Mild Steel, Stainless Steel, Cast Iron, Silicon Bronze, Copper
WARRANTY (Years)
2

MIG WELDING CURRENT RANGE
30-165A
MIG DUTY CYCLE @ 40°C
10% @ 165A
MIG WIRE SIZE RANGE
0.6-0.9mm
MIG WIRE SPOOL SIZE
5kg
MIG WELDING THICKNESS RANGE
1-8mm
DRIVE ROLLER SIZE
30/22

TIG FUNCTION TYPE
DC Lift Arc
TIG WELDING CURRENT RANGE
20-160A
TIG DUTY CYCLE @ 40°C
10% @ 160A
TIG WELDING THICKNESS RANGE
1-6mm

STICK WELDING CURRENT RANGE
20-140A
STICK DUTY CYCLE @ 40°C
10% @ 140A
STICK ELECTRODE RANGE
2.5-4.0mm
STICK WELDING THICKNESS RANGE
2-8mm
